LPL1C

Lightplane 1 Concave (LPL1C) is a suspended, wall or surface mounted luminaire with direct distribution.
The fixture features arching, interior sides that lead to a slightly recessed lens within the channel. With a cross section dimension of just 50mm, the Lightplane 1 Concave body houses a LED driver integral to the channel creating a remarkably low-profile luminaire. For dual direction distribution (indirect and direct), see model LPL1CID.

DOWNLOAD SPEC SHEET

LPL1C
LPL1C
Imperial
Imperial Metric

Downloads

Tech Specs

SIZE

50x71mm

BODY

Aluminum

LENS

Arcylic, PC

FINISH

Black, White, Silver, RAL

LED

Standard CCT: 3000K, 3500K, 4000K, CRI90+ Other option: 2700K, 5000K, 5700K, 6500K, RGB, TUNE(2700K-6500K). Contact factory for details.

DRIVER

Remoted

DIMMING

1-10V / 0-10V dimming, dali dimming, traic dimming. Contact factory for other options.

OPTIONAL ADD-ONS

1.5 hour emergency kit, PIR sensor.

Approvals

  • ETL-cut
  • CE
  • CB
  • rohs
  • IP20
  • IK08

Optics & Features

Icon for 吊灯-只下照
Icon for 吸顶灯
Icon for 壁灯-直照
